ZH200L Vertical Cartoning Machine
The ZH200L Vertical Cartoning Machine is an automatic vertical cartoning machine designed for loose products, bulk products, or products that are not suitable for standard horizontal cartoning. It is usually selected when products need to be filled into cartons from above instead of being pushed horizontally into cartons.
Unlike the ZH200 standard cartoning machine, which is mainly used for common glue sealing or tuck-in cartons with regular product feeding, the ZH200L focuses on vertical carton filling. It is especially useful when the product is loose, scattered, irregular, or needs to be measured before entering the carton.
The ZH200L can work with weighing or dosing equipment such as a multihead weigher, depending on the product and project requirement. In a typical application, products are fed to the weighing or dosing system first, then dropped or filled vertically into opened cartons. After filling, the cartons are closed and discharged to downstream equipment.
This machine should not be positioned as a general-purpose horizontal cartoning machine. It is not mainly selected for regular wrapped products, tissue products, small tuck-in cartons, or special lock-bottom cartons. For common glue sealing or tuck-in cartons, ZH200 is usually the standard model. For tissue products, ZH120 should be considered. For special carton structures such as lock-bottom or long cartons, ZH200G is more suitable.
The ZH200L is suitable when the product characteristics make horizontal pushing difficult or unstable. For example, if the product is loose, granular, small-piece, irregular, or difficult to arrange into a fixed shape before loading, vertical filling may be a better solution.
Before requesting a quotation, buyers should provide product type, product size, product weight per carton, target filling weight or count, product flow condition, carton size, carton material, carton closing method, required speed, weighing or dosing requirement, upstream equipment, downstream equipment, and product videos.
Best fit: ZH200L is best suited for loose or bulk products that need vertical filling into cartons, especially when a standard horizontal cartoning machine cannot handle the product feeding and loading process reliably.
The ZH200L uses a vertical cartoning structure. Instead of pushing products horizontally into cartons, products are filled into cartons from above.
Standard horizontal cartoning machines require products to be arranged and pushed into cartons in a stable way. This works well for regular products, wrapped packs, trays, sachets, blister packs, and other products with controlled shape and orientation.
The ZH200L can be integrated with weighing or dosing equipment such as a multihead weigher, depending on the product and packaging requirement.
The ZH200L can be configured according to the carton closing method. Depending on the carton style, it may be used with suitable glue sealing cartons or tuck-in cartons.
The ZH200L can work as part of a complete packaging line. It can connect with product feeding elevators, multihead weighers, dosing systems, conveyors, checkweighers, labeling machines, case packers, case sealers, and palletizing systems.
This section can show the ZH200L Vertical Cartoning Machine filling loose products into cartons.
Through the video, buyers should check how products are fed, weighed or dosed, filled vertically into cartons, closed, and discharged.
For ZH200L, the most important viewing point is the vertical filling process. Buyers should observe whether the product enters the carton cleanly, whether the filling amount is stable, whether product overflow occurs, and whether the carton remains stable during filling.
If the machine is connected with a multihead weigher, the video should show the coordination between weighing, discharge timing, carton positioning, and carton filling. The product should enter the carton without blocking, scattering, or damaging the carton.
The video should also show carton opening quality, carton closing quality, and downstream transfer. For loose-product applications, the full line must run smoothly from feeding to carton output.
| Model | ZH100 | ZH120 | ZH200 | ZH200G | ZH200A | ZH200L | ZH300 | ZH300A |
|---|---|---|---|---|---|---|---|---|
| Packing speed | 30-70 cartons/min | 80-120 cartons/min | 30-70 cartons/min | 30-70 cartons/min | 30-70 cartons/min | 30-70 cartons/min | 20-50 cartons/min | 30-70 cartons/min |
| Carton size range | L 65-150mm | L 140-250mm | L 120-250mm | L 120-250mm | L 120-250mm | L 150-250mm | L 150-300mm | L 150-300mm |
| W 25-110mm | W 25-120mm | W 45-180mm | W 45-180mm | W 45-180mm | W 90-150mm | W 45-240mm | W 100-240mm | |
| H 15-60mm | H 60-100mm | H 30-100mm | H 30-100mm | H 30-100mm | H 30-90mm | H 30-100mm | H 45-100mm | |
| Servo control | 9 | 10 | 8 | 7 | 17 | 3 | 8 | 17 |
| General power | 9.5KW | 9.5KW | 9.5KW | 8.75KW | 9.5KW | 9.5KW | 9.5KW | 9.5KW |
| Machine weight | 950kg | 1100kg | 900kg | 850kg | 950kg | 950kg | 950kg | 1100kg |
| Machine size | 4250x1715x1700mm | 4525x1960x1840mm | 4263x1715x1900mm | 4290x1715x1700mm | 4290x1715x1700mm | 4290x1715x1900mm | 4452x1810x1915mm | 4290x1715x1900mm |
| Machine body | Carbon steel | Carbon steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel |
| Power supply | 380V/3PH/50Hz | |||||||
| Type of carton | Optional models for glue flap carton or tuck-in flap carton | |||||||
| View machine | View machine | View machine | View machine | View machine | View machine | View machine | ||
The ZH200L can be used as the vertical cartoning unit in automatic packaging lines for loose or bulk products. Its role is to open cartons, receive products from a weighing or dosing system, fill products vertically into cartons, and close the cartons.
Multihead Weigher + ZH200L Vertical Cartoning
A typical line can be configured as:
Product feeding elevator → Multihead weigher → ZH200L vertical cartoning machine → Carton closing → Carton output
This solution is suitable when products need to be weighed before being filled into cartons. The multihead weigher controls the target weight, and the ZH200L completes carton opening, filling, closing, and output.
Loose Product Feeding + Vertical Cartoning
A typical line can be configured as:
Loose product feeding system → Dosing system → ZH200L vertical cartoning machine → Checkweigher
This solution is suitable for loose products that need measured filling into cartons. Product flow and dosing stability should be confirmed before final design.
ZH200L Cartoning + Case Packing Line
A typical line can be configured as:
ZH200L vertical cartoning machine → Checkweigher / Labeling → Case packer → Case sealer → Palletizing
This solution is suitable when finished cartons need to be packed into shipping cases after cartoning.
Complete Loose Product Cartoning System
A complete system can be configured according to product feeding, weighing, carton filling, carton closing, checking, labeling, and secondary packing requirements.
Soontrue Group can design the full line based on product type, target filling weight, carton size, required speed, factory layout, and downstream packaging process.
Soontrue provides automated pet food packaging solutions for dry dog food, cat food, pet food pellets, kibble, pet treats, and other free-flowing pet food products.
The solution is configured according to pellet size, bulk density, surface oil, target pack weight, bag style, required output, and downstream logistics requirements. Depending on the application, the line can include product feeding, weighing, bag forming, pouch filling, sealing, inspection, case packing, and palletizing.
Soontrue provides automated rice and grain packaging solutions for rice, beans, cereals, grains, seeds, and similar free-flowing granular food products.
The solution is designed according to product particle size, bulk density, flowability, target package weight, package format, weighing accuracy, sealing requirements, production speed, and downstream logistics needs. Depending on the application, the packaging process can include material feeding, weighing, dosing, bag forming, filling, sealing, checkweighing, case packing, and palletizing.
Soontrue provides automated salt and sugar packaging solutions for table salt, seasoning salt, sea salt, white sugar, brown sugar, granulated sugar, coarse sugar, and similar small granular products.
The solution is designed according to product particle size, flowability, moisture sensitivity, corrosion risk, clumping tendency, target package weight, packaging format, sealing requirements, production speed, and downstream automation needs. Depending on the application, the packaging process can include material feeding, weighing, dosing, bag forming, filling, sealing, checkweighing, cartoning, case packing, and palletizing.
Soontrue provides automated instant granule packaging solutions for instant drink granules, coffee granules, electrolyte granules, vitamin granules, nutrition granules, probiotic granules, soluble granules, and similar small-dose granular products.
The solution is designed according to product particle size, flowability, moisture sensitivity, target dose, dosing accuracy, package format, sealing requirements, production speed, and downstream cartoning or case packing needs. Depending on the application, the packaging process can include material feeding, dosing, sachet forming, stick pack filling, pouch filling, sealing, cutting, checkweighing, cartoning, case packing, and palletizing.
Soontrue provides automated chemical granule packaging solutions for plastic pellets, masterbatch granules, detergent granules, fertilizer granules, water treatment granules, desiccant granules, additive granules, and other industrial granular materials.
The solution is designed according to material characteristics, including particle size, bulk density, flowability, dust level, abrasiveness, corrosiveness, moisture sensitivity, target package weight, bag strength, sealing requirements, production speed, and downstream logistics needs. Depending on the application, the packaging process can include material feeding, weighing, filling, bag forming, sealing, dust control, checkweighing, case packing, and palletizing.
Soontrue provides automated flour packaging solutions for wheat flour, baking flour, corn flour, starch, rice flour, premix flour, and similar powder products.
The solution is designed according to flour characteristics, including powder fineness, flowability, dust level, moisture sensitivity, bulk density, target package weight, packaging format, sealing requirements, production speed, and downstream automation needs. Depending on the application, the packaging process can include powder feeding, dosing, filling, bag forming, sealing, dust control, checkweighing, case packing, and palletizing.
Soontrue provides automated milk powder packaging solutions for dairy powder, nutrition powder, protein powder, formula-related powder products, and similar fine powder materials.
The solution is designed according to powder characteristics, including powder fineness, bulk density, flowability, dust level, moisture sensitivity, hygiene requirements, target package weight, packaging format, sealing performance, production speed, and downstream automation needs. Depending on the application, the packaging process can include powder feeding, dosing, filling, bag sealing, pouch packaging, checkweighing, cartoning, case packing, and palletizing.
Soontrue provides automated seasoning powder packaging solutions for spice powder, seasoning mix, soup powder, flavor powder, condiment powder, chili powder, pepper powder, and similar powdered seasoning products.
The solution is designed according to seasoning powder characteristics, including powder fineness, flowability, dust level, oil content, stickiness, moisture sensitivity, target dose, packaging format, sealing requirements, production speed, and downstream automation needs. Depending on the application, the packaging process can include powder feeding, dosing, filling, sachet packaging, pouch packaging, sealing, checkweighing, cartoning, case packing, and palletizing.
Soontrue provides automated coffee powder packaging solutions for ground coffee, instant coffee powder, coffee mixes, coffee drink powder, and similar powder products.
The solution is designed according to coffee powder characteristics, including powder fineness, bulk density, flowability, aroma protection requirements, dust level, target package weight, packaging format, sealing performance, production speed, and downstream automation needs. Depending on the application, the packaging process can include powder feeding, dosing, filling, bag sealing, pouch packaging, checkweighing, cartoning, case packing, and palletizing.
Soontrue provides automated detergent powder packaging solutions for laundry detergent powder, washing powder, cleaning powder, dishwashing powder, and similar household chemical powder products.
The solution is designed according to powder characteristics, including particle size, bulk density, flowability, dust level, fragrance sensitivity, moisture sensitivity, target package weight, packaging format, sealing requirements, production speed, and downstream automation needs. Depending on the application, the packaging process can include powder feeding, weighing, dosing, bag forming, filling, sealing, dust control, checkweighing, case packing, and palletizing.
Soontrue provides automated chemical powder packaging solutions for additive powder, pigment powder, cleaning powder, industrial powder, desiccant powder, water treatment powder, and other non-food powder materials.
The solution is designed according to powder characteristics, including powder fineness, bulk density, flowability, dust level, abrasiveness, corrosiveness, moisture sensitivity, target package weight, packaging material, sealing requirements, production speed, and downstream logistics needs. Depending on the application, the packaging process can include powder feeding, dosing, filling, bag forming, sealing, dust control, checkweighing, case packing, and palletizing.
Soontrue packaging machines support various flexible packaging formats to meet different product shapes, sizes and production requirements. From standard pillow bags to customized bag options, we provide reliable packaging solutions for diverse applications.
The ZH200L is used for automatic vertical cartoning of loose or bulk products. It fills products into cartons from above and then closes the cartons according to the configured carton style.
Choose ZH200L when your product is loose, bulk, irregular, or difficult to push horizontally into cartons. It is usually selected when a standard horizontal cartoning machine cannot handle the product properly.
ZH200 is a standard horizontal cartoning machine for common glue sealing or tuck-in cartons. ZH200L is a vertical cartoning machine for loose or bulk products that need to be filled from above.
For regular wrapped products that can be fed and pushed horizontally into cartons, ZH200 may be more suitable. ZH200L is mainly for loose or bulk product filling.
Yes. ZH200L can work with a multihead weigher or other dosing systems, depending on the product and filling requirement.
It is suitable for loose products, bulk products, small-piece products, granular products, weighed products, counted products, and other products confirmed by sample testing.
It can be configured for suitable glue sealing cartons. Glue position, carton material, carton coating, and glue system requirements should be confirmed with carton samples.
It may be configured for suitable tuck-in cartons. Carton tongue length, folding line quality, carton stiffness, and carton closing stability should be confirmed.
Product flowability, product size, product shape, stickiness, dust condition, filling weight, drop height, filling chute design, carton opening size, and dosing accuracy all affect filling performance.
