Automatic Packaging System for Swiss Roll and Similar Products
The Automatic Packaging System for Swiss Roll and Similar Products is a product-specific primary packaging system designed for swiss rolls, soft roll-shaped bakery products, and similar cylindrical products that require automatic feeding, orientation control, up-and-down transfer, wrapper infeed synchronization, and flow wrapping.
Swiss rolls are different from flat cakes or tray-packed cakes. Their cylindrical or roll-shaped structure means they may rotate, shift, or lose orientation during conveying and transfer. If the product direction is not controlled before entering the flow wrapping machine, the final package may have poor alignment, incorrect cutting position, unstable sealing, or unattractive appearance.
The key feature of this system is the up-and-down feeding method combined with product orientation control. Products are transferred into each flow wrapping machine infeed or packaging machine tailstock through a lifting and lowering transfer structure. This helps match the height, position, and timing required by the wrapper infeed.
This system can be used for swiss rolls, mini swiss rolls, cream rolls, soft roll cakes, cylindrical bakery products, and similar products confirmed by testing. The final configuration depends on product diameter, length, softness, filling condition, surface condition, product spacing, wrapper model, required speed, and factory layout.
Before requesting a quotation, buyers should provide product diameter, product length, product weight, product softness, product surface condition, product orientation requirement, production speed, number of wrappers, film type, package size, factory layout, and product running videos.
Best fit: This system is best suited for swiss rolls and similar roll-shaped bakery products that require controlled orientation, anti-rolling transfer, up-and-down feeding, and flow wrapping.
The system uses an up-and-down feeding structure to transfer swiss rolls into each flow wrapping machine infeed or tailstock. This feeding method is suitable when the packaging line layout requires height-level transfer or controlled product delivery into the wrapper infeed.
Swiss rolls and similar products usually require stable orientation before packaging. If the roll is not aligned correctly, the product may enter the wrapper at the wrong angle, which can affect film forming, cutting position, and final package appearance.
A key challenge in swiss roll packaging is preventing product rolling during transfer. When a cylindrical product moves through conveyors, height transitions, or infeed sections, uncontrolled rolling may cause misalignment and unstable packaging.
Swiss rolls are often soft and may contain cream, filling, coating, or delicate surface layers. The feeding and transfer system should avoid excessive pressure, sharp turns, sudden drops, or hard pushing that may damage the product.
After orientation control and up-and-down feeding, the swiss roll enters the flow wrapping machine for pillow-type packaging. The wrapper forms film around the product, completes longitudinal sealing, and finishes end sealing and cutting.
This section can show the full process of swiss roll feeding, orientation control, up-and-down transfer, wrapper infeed, and flow wrapping.
Through the video, buyers should check how swiss rolls move from the upstream conveyor, how the system controls product orientation, how the up-and-down transfer feeds products into the wrapper infeed, and whether the products remain stable before wrapping.
For this system, the key viewing point is not only wrapper speed. Buyers should observe whether the product rolls, rotates, shifts, or deforms during transfer. The video should show whether the roll direction remains consistent before entering the flow wrapping machine.
If the swiss roll is soft, cream-filled, or surface-sensitive, the video should also show whether the feeding system protects the product during transfer.
A good video should help buyers understand the complete process:
Swiss roll feeding → Orientation control → Up-and-down transfer → Wrapper infeed → Flow wrapping → Finished pack output
If the system includes downstream equipment, the video can also show checkweighing, metal detection, cartoning, case packing, or other secondary packaging processes.
The Automatic Packaging System for Swiss Roll and Similar Products can be configured according to product shape, orientation requirement, production capacity, and line layout.
Single-Wrapper Swiss Roll Packaging Line
A typical line can be configured as:
Swiss roll feeding → Orientation control → Up-and-down transfer → Wrapper infeed → Flow wrapping machine → Finished pack output
This solution is suitable for production lines with moderate capacity where one flow wrapping machine can meet the required output.
Multi-Wrapper Swiss Roll Packaging Line
A typical line can be configured as:
Swiss roll production output → Product conveying → Orientation control → Up-and-down feeding units → Multiple wrapper infeeds → Flow wrapping machines
This solution is suitable when the upstream output requires multiple packaging machines to share the product flow.
Swiss Roll Flow Wrapping + Inspection
A typical line can be configured as:
Swiss roll feeding → Up-and-down transfer → Flow wrapping → Checkweigher / Metal detector → Rejection system
This solution is suitable when finished packs require weight checking, metal detection, or defective pack rejection.
Swiss Roll Flow Wrapping + Secondary Packaging
A typical line can be configured as:
Swiss roll feeding → Up-and-down transfer → Flow wrapping → Cartoning / Case packing → Case sealing
This solution is suitable when individual swiss roll packs need to enter secondary packaging after primary flow wrapping.
Complete Swiss Roll Packaging Line
A complete line can be configured as:
Swiss roll production output → Product conveying → Orientation control → Up-and-down feeding → Wrapper infeed → Flow wrapping → Coding → Checkweighing → Cartoning or case packing → Palletizing
Soontrue Group can configure the full system according to swiss roll size, product softness, orientation requirement, package size, required capacity, factory layout, and downstream packaging process.
Soontrue provides automated cake packaging solutions for cakes, sponge cakes, cream cakes, cupcakes, and other delicate bakery products.
The solution is designed according to cake characteristics, including product size, shape, softness, surface condition, fragility, production speed, packaging format, and downstream automation requirements. Depending on the application, the packaging process can include gentle product feeding, alignment, wrapping, bagging, cartoning, case packing, and end-of-line automation.
Soontrue provides automated cake packaging solutions for cakes, sponge cakes, cream cakes, cupcakes, and other delicate bakery products.
The solution is designed according to cake characteristics, including product size, shape, softness, surface condition, fragility, production speed, packaging format, and downstream automation requirements. Depending on the application, the packaging process can include gentle product feeding, alignment, wrapping, bagging, cartoning, case packing, and end-of-line automation.
Soontrue provides automated cupcake packaging solutions for cupcakes, muffins, mini cakes, and other individual bakery products.
The solution is designed according to cupcake characteristics, including product size, shape, softness, topping condition, packaging requirements, production speed, and downstream automation needs. Depending on the application, the packaging process can include product feeding, positioning, wrapping, bagging, cartoning, case packing, and end-of-line automation.
Soontrue provides automated bread packaging solutions for toast, sliced bread, buns, soft bread, and other bakery products.
The solution is designed according to bread shape, size, softness, production speed, packaging format, and downstream automation requirements. Depending on the application, the packaging process can include product feeding, alignment, flow wrapping, bagging, cartoning, case packing, and palletizing.
Soontrue provides automated bakery packaging solutions for a wide range of baked products, including bread, biscuits, cookies, cakes, cupcakes, Swiss rolls, pastries, and other bakery items.
The solution is designed according to product characteristics, including product shape, size, texture, fragility, production speed, packaging format, and downstream automation requirements. Depending on the application, the packaging process can include product feeding, sorting, alignment, wrapping, bagging, cartoning, case packing, and end-of-line automation.
Soontrue packaging machines support various flexible packaging formats to meet different product shapes, sizes and production requirements. From standard pillow bags to customized bag options, we provide reliable packaging solutions for diverse applications.
The standard pillow bag features a simple and efficient sealing structure, making it one of the most widely used flexible packaging formats. It is suitable for a wide range of products across food, daily goods, and industrial applications.
A pillow bag with additional gusset folds on the side or bottom, providing increased capacity and better package stability. It is suitable for products requiring more volume or improved shelf appearance.
Multiple pillow bags are connected together through perforated sections, creating a convenient multipack format for retail, promotion, and bundled product applications.
A pillow bag equipped with a reinforced Euro hole for hanging display. It provides a practical retail presentation option while maintaining the advantages of the pillow bag structure.
It is used for automatic feeding, orientation control, up-and-down transfer, and flow wrapping of swiss rolls and similar roll-shaped bakery products.
Swiss rolls are cylindrical or roll-shaped products. If they roll, rotate, or enter the wrapper at an unstable angle, the final package may have poor alignment, wrong cutting position, or unstable sealing.
The system can be designed with suitable conveyors, guides, transfer structures, and feeding timing to help keep the roll direction stable before entering the wrapper.
Yes, it can be configured for soft or cream-filled rolls. Product softness, filling condition, surface condition, and shape stability should be confirmed through samples or product videos.
Yes. The system can be designed for one or multiple wrapper infeeds depending on production capacity and factory layout.
Please provide product diameter, product length, product weight, product softness, product photos or videos, orientation requirement, target speed, number of wrappers, film type, package size, and factory layout.
Up-and-down feeding refers to a lifting and lowering transfer method that feeds products into each packaging machine infeed or tailstock through a height-level transfer structure.
